General Specifications

Frequency Range

VHF:136-174MHz(220-260MHz)

UHF:400-480MHz(350MHz-390MHz)

Channel Capacity

200 channels

Channel Spacing

25KHz, 20KHz, 12.5KHz

Channel Step

2.5KHz, 5KHz, 6.25KHz, 10KHz, 12.5KHz, 15KHz, 25KHz

Working Voltage

13.8V DC ±15%

Squelch way

CARRIER / CTCSS / DCS / 5Tone / 2Tone / DTMF

Frequency Stability

±2.5ppm

Operating Temperature

-20℃~+60℃

Dimension(W*H*D)

98(W)*43(H)*126(D)mm

Weight

448g

Receiver

Wide Band

Narrow band

Sensitivity

≤0.25μV

≤0.35μV

Channel chioce

≥70dB

≥60dB

Intermodulation

≥65dB

≥60dB

Spurious Rejection

≥70dB

≥70dB

Audio response

+1~ -3dB(0.3~3KHz)

+1~ -3dB(0.3~2.55KHz)

Signal to noise ratio

≥45dB

≥40dB

Audio distortion

≤5%

Audio output power

≥2W±10%

Transmitter

Wide Band

Narrow band

Output power

25W/20W (VHF / UHF)

Modulation Mode

16KΦF3E

11KΦF3E

Channel Power

≥70dB

≥60dB

Signal noise ratio

≥40dB

≥36dB

Parasitic harmonic

≥60dB

≥60dB

Audio response

+1~ -3dB(0.3~3KHz)

+1~ -3dB(0.3~2.25KHz)

Audio distortion

≤5%
